Description This DomaeAD63 K is a residual current breaker with overcurrent protection (RCBO). It is a 1P+N residual current device, 20A rated current and C tripping curve. The earth leakage protection class is A type with a sensitivity of 30mA. The earth-leakage protection time delay is instantaneous. The Icn rated short circuit breaking capacity is up to 6000A. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. This product is compliant with AS/NZS 61009 and IEC 61009-1 standards. It has a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 230VAC or 240VAC. The Ui rated insulation voltage is 400VAC. The frequency is 50Hz. It is DIN rail mountable. The width in 9mm pitches is 2. The product color is light grey (RAL7035). The dimensions are (W) 18mm x (H) 93mm x (D) 70mm. The weight is 136g. It has an IP20 degree of protection (as per IEC/EN 60529 standard) and becomes IP40 once in modular enclosure. The operating temperature is from -25°C to 55°C. The storage temperature is from -30°C to 70°C.
SKUs 0000241614
Supplier Part #(s) DOM12532
Pack Size 1

Number of poles (total).03
Rated current20A
Rated fault current.03A
Rated short-circuit breaking capacity EN 608986kA
Release characteristicA
