DOM11375 DOMAE MCB 1P 6A C 230V 6KA
0000624614
| Price | LOGIN FOR PRICE |
|---|---|
| Description | This Domae product is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected poles and 6A In rated current and C tripping curve. The Icn rated short circuit breaking capacity is up to 6000A at 230VAC or 400VAC conforming to EN/IEC 60898-1 standard. This product complies with IEC 60898-1 standard. This miniature circuit breaker protects circuit against short circuit and overload current. The fault tripping is indicated on the front panel by the position of the handle (O-I engraved). Mechanical durability goes up to 10000 cycles and electrical durability goes up to 20000 cycles. The Ue operational voltage is 230VAC or 400VAC. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The product colour is light grey (RAL7035). The dimensions are (W) 18 mm x (H) 81 mm x (D) 78.5 mm. The weight is 0.095kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 70°C. |
| SKUs | 0000624614 |
| UOM | EA |
| Supplier | SCHNEIDER ELECTRIC LTD (EDI) |
| Supplier Part #(s) | DOM11375 |
| Pack Size | 12 |
