Price LOGIN FOR PRICE
Description This Domae product is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected poles and 32A In rated current and C tripping curve. The Icn rated short circuit breaking capacity is up to 6000A at 230VAC or 400VAC conforming to EN/IEC 60898-1 standard. This product complies with IEC 60898-1 standard. This miniature circuit breaker protects circuit against short circuit and overload current. The fault tripping is indicated on the front panel by the position of the handle (O-I engraved). Mechanical durability goes up to 10000 cycles and electrical durability goes up to 10000 cycles. The Ue operational voltage is 230VAC or 400VAC. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The product colour is light grey (RAL7035). The dimensions are (W) 18 mm x (H) 81 mm x (D) 78.5 mm. The weight is 0.095kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 70°C.
SKUs 0000624619
UOM EA
Supplier SCHNEIDER ELECTRIC LTD (EDI)
Supplier Part #(s) DOM11380
Pack Size 12

AC_Manual00254463/SCH-DOM11380_Datasheet1.pdf
Release characteristicA
Number of poles (total)1
Rated current32A
Rated voltage230V
Rated short-circuit breaking capacity Icn EN 60898 at 400 V6kA
